175-196M 10/24/2005
Great Plains Mfg., Inc.
1300 Fertilizer Assembly Upgrade 8
175-210A 1300 13’ Fertilizer Upgrade 7 1/2
Your kit includes:
1 175-186K 1300 FERT DRIVE SUB ASSEMBLY
1 178-188K 1300 FERT TRAY ASSEMBLY 7 1/2
1 175-190S 1300 SPILL FLAP SUB ASSEMBLY
1 175-191S 1300 SEED/FERT FLAP SUB ASSEMBLY
1 175-212L 1300 FERT UPGRADE BOX OF PARTS
1 175-214L 1300 FERT DROP TUBE BOX 7 1/2
2 175-327D 1300 HINGE CLAMP STRIP END
2 195-197D HINGE CLAMP STRIP CTR
21 800-009C CLAMP HOSE 1 5/8 NO. 26
21 816-007C SEED HOSE X 59 RIBS 1.5 -1.2
4 817-321C DIVIDER INSERT 33 X NO OFFS
1 175-196M MANUAL 1300 FERTILIZER ASSEMBLY UPGRADE
Qty. Part No. Part Description
175-212L 1300 Fert Upgrade Box Of Parts
Your kit includes:
4 195-194D DIVIDER CLIP, END MOUNTED
6 195-205D DIVIDER ANGLE BRACKET
6 195-206D DIVIDER CLIP INNER
6 195-207D DIVIDER CLIP OUTER
1 175-197B 1300 FERT COMMON BLT BAG
1 813-033C BOX 16 1/2 X 16 1/2 X 5 1/2
1 818-837C DECAL FERTILIZER RATE 13’ EW
1 818-838C DECAL FERT CHAIN ROUTE 13’
3 890-308C 9 1/4-15 x 70LB GAS SPRING
2 195-181H DIVIDER BOTTOM BRACKET CTR
1 195-182H DIVIDER BOTTOM BRACKET LH
1 195-183H DIVIDER BOTTOM BRACKET RH
12 195-208D RETAINER CLIP
1 890-179C SILICON 35YR CLEAR 5.5OZ #22723
Qty. Part No. Part Description
175-197B 1300 Fert Common BLT Bag
Your kit includes:
1 136-031D CHAIN RL #40 90 PITCHES
1 136-033D CHAIN RL #40 125 PITCHES
12 802-005C HHCS 1/4-20 X 1 GR5
8 802-017C HHCS 3/8-16 X 1 GR5
19 802-196C HFSS 1/4-20 X 5/8 GR5
22 802-375C HFSS 1/4-20 X 1 GR5
12 802-387C HFS 5/16-18 X 3/4 GR5
21 802-442C HFSS 5/16-18 X 1 1/4
12 803-007C NUT LOCK 1/4-20 PLT
6 803-011C NUT LOCK 5/16-18 PLT
4 803-020C NUT HEX 1/2-13 PLT
41 803-088C NUT HEX LOCK 1/4-20 FLG
33 803-199C NUT HEX FLANGE 5/16-18
8 803-209C NUT FLANGE LOCK 3/8-16 PLT
4 804-015C WASHER LOCK SPRING 1/2 PLT
2 806-005C U-BOLT 1/2-13 X 2 X 3 GR5
1 808-143C SPKT 40B12 7/8 HEX BORE
1 813-026C 8 X 12 WOVEN POLYPROPYLENE BAG
12 817-324C KNOB 1/4-20 FEMALE THD
Qty. Part No. Part Description
