Crimestopper Security Products EZ-84FM - Manual (Page 15)

15
TRANSMITTER PROGRAMMING
Note: All transmitter codes must be learned at time of programming!! The unit will learns up to 4 different
transmitter codes.
1. Turn key to the ON position.
2. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times.
3. Press button #1 & #2 together of the transmitter to be coded. You should get 2 light flashes indicating the unit is
waiting for a 2 nd code, then press button #1 & #2 of a second transmitter, the unit will flash 3 times indicating its
waiting for the 3 rd code and so on. If all 4 codes are learned, the unit will automatically exit code learning mode,
otherwise turn key off. See diagram below.
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
IGN
OFF
1-WAY
START
EZ START
PRESS TOGETHER
