Figure 4, As shown in figure 4. do not tighten these – Wheatheart X13 Right Angle Drive Kit User Manual

Page 4

background image

4

Figure 4 Installing Gearbox and Jack Mount

GEARBOX / ADJUST
PLATE NUTS [19600]

GEARBOX MOUNT
ASSEMBLY [20110]

HITCH TUBE [29983]

5/8” X 5-1/2” BOLTS [20164]

5/8” LOCKNUTS [19600]

JACK MOUNT [20107]
