part Description Qty
1 Bearing Set 1
2 Bearing 60017 1
3 Armature 1
4 Check Ring φ10 2
5 Screw M4x10 2
6 Bearing 60100 1
7 Spindle Lock Button 1
8 Spring 1
9 Gear Box 1
10 Screw 4
11 Check Ring φ5 1
12 Bearing φ12Xφ8X10 1
13 Spring Washer φ10 1
14 Gear 1
15 Screw M4X12 2
16 Bearing 80201 1
17 Front Cap 1
18 Spring Washer φ4 11
19 Screw M4X14 2
20 Woodruff-Key 3X10 1
21 Spindle 1
22 Screw M6X14 2
23 Upper Handle 1
24 Handle(L) 1
25 Handle(R) 1
26 Cord Clamp 1
27 Screw ST4.2X13 2
28 Capacitor 1
29 Trigger 1
30 Screw ST4.2X16 5
31 Cord Plug 1
32 Cord Protector 1
33 Brush Cap (R) 1
34 Brush Cap(L) 1
35 Brush Spring 1
36 Label 2
37 Screw ST3.5X10 4
38 Brush 2
39 Brush Holder 2
40 Roller φ3X4.9 1
41 Housing 1
42 Stator 1
43 Screw M4X55 2
45 Pinion 1
part Description Qty
46 Spring Washer φ8 1
47 Nut M8 1
49 Fan Guide 1
50 Spanner Wrench 1
51 Inner Flange 1
52 Blade 1
53 Outer Flange 1
54 Flat Screw M4X8 2
55 Depth Setting Bolt M4X25 1
56 Depth Base Block 1
57 Depth Slide Plate 1
58 Guide Bar 1 1
59 Screw M4X14 4
60 Guide Bar 2 1
61 Spring 2
62 Set Screw M4 1
63 Compressing Spring 1
64 Steel Ball φ3 1
65 Depth Adjustment Dial 1
66 Shoulder Screw M5X12 1
67 Slide Plate 1
68 Base Plate 1
69 Flat Screw M4X6 4
70 Screw M3X6 2
71 Depth Mark 1
72 Support Stand Board 1
73 Allen Bolt M4X16 2
74 Height Locking Knob 1
75 Pressed Block 1
76 Height Fence 1
77 Depth Pointer 1
78 Screw M4X14 1
79 Angle Pointer 1
80 Dowel 2
81 Angle Fence 1
82 Angle Ruler 1
83 Sink Screw 2
84 Angle Locking Knob 1
85 Dust Port 1
86 Dust Chute 1
87 Dust Bag 1
88 Nut 1
89 Cap 2
90 Spring Washer 65Mn(φ4) 2
parts list and Diagram
plEaSE REaD thE FOllOWinG caREFully
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
qUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS qUALIFIED TO REPLACE
Any PARTS oF The PRoDuCT. In FACT, The MAnuFACTuReR AnD/oR DISTRIBuToR eXPReSSLy
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts list
