64
REAR FLUE OUTLET CARTON
KEY DESCRIPTION
CROWN
PART #
QUANTITY
7
8
10
12
20A
7" REAR OUTLET DAMPER ASSY
333007
1
8" REAR OUTLET DAMPER ASSY
333008
1
10" REAR OUTLET DAMPER ASSY
333010
1
12" REAR OUTLET DAMPER ASSY
333012
1
21B
TOP OUTLET COVER, 7"& 8" OPENING
333017
1
1
TOP OUTLET COVER, 10" OPENING
333020
1
TOP OUTLET COVER, 12" OPENING
333022
1
8"
4"
B.M.P., 4" CARTON COMPLETE*
330404
0
1
B.M.P., 8" CARTON COMPLETE*
330408
1
0
5/16 X 1" CAP SCREW
900410
8
8
5/16" WASHER
900102
8
8
3/8 X 7/8 CAP SCREW
900450
5
5
3/8 FLAT WASHER
90-036
4
4
3/8 LOCK WASHER
9
9
FLEXROPE, 3/16" DENSE
333005
6.5 ft
6.5 ft
SHUTTER DOOR ASSEMBLY INCLUDES:
HANDLE KNOB
1
1
SHUTTER HANDLE
1
1
SHUTTER SPRING
1
1
OBSERVATION PORT SHUTTER
1
1
SPRING PIN
1
1
OBSERVATION PORT ASSEMBLY INCLUDES:
OBSERVATION PORT COVER
1
1
OBSERVATION PORT OUTER GASKET
1
1
OBSERVATION PORT GLASS
1
1
OBSERVATION PORT INNER GASKET
1
1
* INCLUDES B.M.P. AND ALL ITEMS LISTED BELOW INCLUDING THE SHUTTER
DOOR ASSY AND OBSERVATION PORT ASSY.
BURNER MOUNTING PLATE CARTON
KEY
24
25
23
QUANTITY
CROWN
PART #
DESCRIPTION
BURNER ADAPTOR PLATE CARTON
KEY DESCRIPTION
CROWN
PART #
QUANTITY
920
921
922
923
924
28
BECKETT B.A.P. ASSY, 920
330400
1
BECKETT B.A.P. ASSY, 921
330401
1
BECKETT B.A.P. ASSY, 922
330402
1
BECKETT B.A.P. ASSY, 923
330403
1
BECKETT B.A.P. ASSY, 924
330404
1
BURNER ADAPTOR PLATE GASKET
333405
1
1
1
REAR FLAME OBSERVATION PORT CARTON
KEY DESCRIPTION
CROWN
PART #
QUANTITY
29
REAR FLAME OBSERVATION PORT ASSY
333000
1
5/16 X 1" CAP SCREW
4
5/16" WASHER
4
FLEXROPE, 3/16" DENSE
333005
2.83 ft
REAR TARGET WALL CARTON
DESCRIPTION
CROWN
PART #
QUANTITY
TARGET WALL
335025
1
