Fitting your extractor to the wall
Insert the 4 wall plugs in to the holes and fix 2 screws in
the top holes so that they are protruding from the wall by
approx 5mm (fig 12).
Next, lift the hood onto the 2 screws as shown in (fig12).
Secure the top two screws and fix the hood into position
using screws inserted into the 2 lower holes (fig 13). The
extractor is now secured to the wall.
Using the extractor as a
recirculation device
Refit the top cover and grill as below before proceeding
to fit the charcoal filter – locate each filter onto the motor
housing spigot and rotate to lock into position.
Fig. 13
Fig. 12
Fig. 14
