Model rbs, Dimensional data, Model rbs reel brake description – Wichita Clutch Motor RB Tension Brake User Manual
Page 5: All dimensions in inches
Static
Dynamic
Torque @
Torque @
Thermal
Weight
Weight
WR
2
RBS
60 PSIG
60 PSIG
Capacity
Inner
Total
Inner
H
I
Model
(lb.-in.)
(lb.-in.)
(ft. lbs./min.)
(lbs.)
(lbs.)
(lb.-ft
2
)
A
B
C
D
E
F
G
No.
Size
No. Size
J
K
RBS-110
3,577
3,100
17,000
6.70
49.0
.54
3.44
1.15
5.376
12.25
6.125
4.25
7.13
6
5/16
6
3/8
5.250
1/4
RBS-210
7,270
6,300
25,650
12.20
56.0
.98
4.63
RBS-112
7,500
6,500
27,000
9.25
71.0
1.05
3.69
1.15
6.376
14.63
7.250
4.63
8.00
6
5/16
8
1/2
5.875
1/4
RBS-212
15,000
13,000
40,500
16.50
81.0
1.91
4.94
RBS-115
16,000
13,900
39,270
11.25
109.0
2.66
4.13
1.15
9.000
17.88
9.750
7.13
10.00
12
5/16
8
1/2
8.500
1/4
RBS-215
32,000
27,800
58,900
20.50
124.0
4.57
5.38
DIMENSIONAL DATA
All dimensions in inches
NOTES: 1.) Torque capacity based on 60 PSIG release pressure.
2.) Optional Conversion Kit: Permits conversion of single disc model to double
disc model. Consists of: Center plate, disc assembly, stud extensions, screws.
3.) Use certified drawing dimensions only for final layouts.
4.) DXF and IGES files available upon request.
5.) Dimensions subject to change without notice.
MODEL RBS REEL BRAKE DESCRIPTION
The Model RBS brake is identical to our Model RB brake
except that this model is spring set and air released.
Air pressure applied to the brake can be varied to adjust the
torque desired or to fully release the brake. The absence of
air pressure allows the brake to operate fully engaged for
those applications requiring full holding torque under these
conditions.
I N D U S T R I A L C L U T C H P R O D U C T S
5
K
H
D
D
C
C
E
E
G
G
F
F
I
J
J
I
A
B
B
A
K
H
CENTER PLATE
STUD EXTENSION
DISC
ASSEMBLY
SCREW
SINGLE DISC
DOUBLE DISC (see note 2)
Model RBS
