Page 4: All dimensions in inches
4
I N D U S T R I A L C L U T C H P R O D U C T S
STUD
EXTENSION
CENTER
PLATE
SCREW
DISC
ASSEMBLY
D
D
C
C
E
E
G
G
F
F
A
B
B
A
I
I
J
J
H
K
H
K
SINGLE DISC
DOUBLE DISC (see note 2)
Static
Dynamic
Torque @
Torque @
Thermal
Weight
Weight
WR
2
RB
60 PSIG
60 PSIG
Capacity
Inner
Total
Inner
H
I
Model
(lb.-in.)
(lb.-in.)
(ft. lbs./min.)
(lbs.)
(lbs.)
(lb.-ft
2
)
A
B
C
D
E
F
G
No.
Size
No. Size
J
K
RB-110
3,577
3,100
17,000
6.70
45.0
.54
2.75
.50
5.376
12.25
6.125
4.25
7.13
6
5/16
6
3/8
5.250
1/4
RB-210
7,270
6,300
25,650
12.20
52.0
.98
3.94
RB-112
7,500
6,500
27,000
9.25
65.0
1.05
3.00
.50
6.376
14.63
7.250
4.63
8.00
6
5/16
8
1/2
5.875
1/4
RB-212
15,000
13,000
40,500
16.50
75.0
1.91
4.25
RB-115
16,000
13,900
39,270
11.25
99.0
2.66
3.38
.50
9.000
17.88
9.750
7.13
10.00
12
5/16
8
1/2
8.500
1/4
RB-215
32,000
27,800
58,900
20.50
114.0
4.57
4.63
DIMENSIONAL DATA
All dimensions in inches
NOTES: 1.) Torque capacity based on 60 PSIG air pressure. Maximum air pressure
= 60 PSIG
2.) Optional Conversion Kit: Permits conversion of single disc model to double
disc model. Consists of: Center plate, disc assembly, stud extensions, screws.
3.) Use certified drawing dimensions only for final layouts.
4.) DXF and IGES files available upon request.
5.) Dimensions subject to change without notice.
MODEL RB REEL BRAKE DESCRIPTION
The Model RB brake was originally designed as an economi-
cal modular brake for use on reels as an alternative to electric
brakes.
The unique modular design allows either a single or double
disc unit to be installed within the same mounting bolt circle
by simply changing the stud extensions and adding or
removing the appropriate components. Conversion kits are
available for this purpose.
The Model RB brake exhibits quiet operation, consistent
torque capacity, long life, and the ruggedness necessary for
emergency stops at an economical price.
Model RB
