Air Tube Disc Clutches and Brakes
60 Wichita Clutch 800-964-3262 P-1100-WC 1/12
Spring-Set Brakes
Specifications
Model Assembly Slip Torque Capacity Max. Bore
Size Number lb.in. Nm Rect. Key
ATD- 60 PSI Release 60 PSI 75 PSI 90 PSI 4.1 BAR 5.2 BAR 6.2 BAR in. (mm)
SSB 104H 71104-730* 451 51 1.00 (25)
SSB 106 7-106-100-200-0 2,225 2,900 3,700 251 328 418
SSB 206 7-106-200-200-0 4,300 5,600 7,200 486 633 813 2.00 (50)
SSB 306 7-106-300-100-0* 5,750 7,400 9,050 650 836 1,022
SSB 108 7-108-100-123-0 3,700 4,800 6,200 418 542 700
SSB 208 7-108-200-121-0 7,100 9,100 12,000 802 1,028 1,356 2.25 (57)
SSB 308 7-108-300-101-0 8,800 11,300 13,400 994 1,277 1,514
SSB 111 7-111-100-102-0 8,200 10,500 11,600 926 1,186 1,311
SSB 211 7-111-200-100-0 15,600 20,000 22,200 1,763 2,260 2,508 2.50 (64)
SSB 311 7-111-300-100-0 19,300 24,900 28,400 2,181 2,813 3,209
SSB 114 7-114-100-127-0 14,500 18,600 24,700 1,638 2,101 2,791
SSB 214 7-114-200-103-0 27,600 35,400 46,300 3,118 4,000 5,231 3.50 (89)
SSB 314 7-114-300-100-0 36,000 44,700 53,900 4,067 5,050 6,090
SSB 116 7-116-100-100-0 19,300 23,800 28,400 2,181 2,689 3,209
SSB 216 7-116-200-100-0 35,300 44,700 53,400 3,988 5,050 6,033 4.00 (102)
SSB 316 7-116-300-100-0 49,500 62,600 75,000 5,593 7,073 8,474
SSB 118 7-118-100-100-0 31,400 40,400 51,600 3,548 4,564 5,830
SSB 218 7-118-200-100-0 60,000 77,000 100,000 6,779 8,700 11,298 4.75 (120)
SSB 318 7-118-300-100-0 80,900 102,000 122,000 9,140 11,524 13,784
SSB 121 7-121-100-100-0 38,300 47,400 57,400 4,327 5,355 6,485
SSB 221 7-121-200-100-0 71,700 88,800 107,600 8,101 10,033 12,157 6.00 (152)
SSB 321 7-121-300-101-0 100,200 124,100 150,400 11,321 14,021 16,992
SSB 124H 7-125-100-100-0 75,500 86,600 — 8,530 9,784 —
SSB 224H 7-125-200-100-0 137,000 161,200 — 15,478 18,213 — 6.00 (152)
SSB 324H 7-125-300-100-0 178,900 223,600 — 20,212 25,263 —
SSB 127 7-127-100-105-0 75,300 94,200 113,400 8,508 10,643 12,812
SSB 227 7-127-200-118-0 140,900 176,200 212,100 15,919 19,907 23,963 6.50 (165)
SSB 327 7-127-300-102-0 196,700 245,900 296,000 22,223 27,782 33,443
SSB 130H 7-131-100-101-0 162,200 211,700 260,500 18,326 23,918 29,432
SSB 230H 7-131-200-100-0 310,000 404,500 495,500 35,024 45,701 55,982 7.25 (184)
SSB 330H 7-131-300-305-0 395,500 496,100 589,900 44,684 56,050 66,648
SSB 136H 7-137-100-100-0 254,500 300,000 400,000 28,754 33,894 45,193 9.00 (229)
SSB 236H 7-137-200-104-0 477,500 564,000 760,000 53,949 63,722 85,866 10.00 (254)
SSB 336H 7-137-300-101-0* 675,000 840,100 1,012,600 76,263 94,916 114,405 10.00 (254)
SSB 436H 7-137-400-102-0 868,800 1,081,300 1,303,400 98,158 122,167 147,260 10.00 (254)
SSB 142 7-142-100-302-0 425,000 48,017
SSB 242 7-142-200-306-0 796,000 89,933 14.00 (355)
SSB 342 7-142-300-301-0 1,072,000 121,116
SSB 148 7-148-100-300-0 698,250 78,889
SSB 248 7-148-200-300-0 1,335,000 150,830 18.00 (455)
SSB 348 7-148-300-103-0 1,726,000 195,006
SSB 260 7-160-200-300-0 3,255,000 367,755
SSB 360 TBD 4,921,000 555,982 19.00 (480)
SSB 460 TBD 5,355,000 605,016
* Not the standard 60 PSI release pressure. See following pages for release pressure per assembly.
