Wichita Clutch LI SSB - Low Inertia Spring Set Brake - Manual (Page 12)

B
Air Tube Disc Clutches and Brakes
P-1100-WC 1/12 Wichita Clutch 800-964-3262 69
Model B C
Size ATD- A Hole Circle Pilot D E F G H
SSB 106 8.75 8.000 7.377 / 7.379 8.81 5.47 (138.9) 2.00 (50.8) 0.00 (0.0) 4.22 (107.2)
SSB 206 (222.3) (203.20) (187.38 / 187.43) (223.8) 6.66 (169.2) 3.25 (82.6) 0.06 (1.5) 5.44 (138.2)
SSB 142 52.00 49.250 44.625 / 44.628 49.00 12.28 (311.9) 5.63 (143.0)
1.00 (25.40)
9.69 (246.1)
SSB 242 (1,320.8) (1,250.95) (1,133.48 / 1,133.55) (1,244.6) 16.03 (407.2) 7.50 (190.5) 13.44 (341.4)
SSB 148 61.00 58.000 52.000 / 52.005 56.75 15.00 (381.0) 6.00 (152.4) 0.00 (0.0) 11.19 (284.2)
SSB 248 (1,549.4) (1,473.20) (1,320.80 / 1,320.93) (1,441.5) 19.33 (491.0) 8.75 (222.3) 1.00 (25.4) 15.5 (393.7)
SSB 260
1
70.50 66.500 62.750 / 62.760 70.50 22.31 (566.7) 9.38 (238.3)
0.25 (6.40)
17.61 (447.3)
SSB 360 1 (1,790.7) (1,689.10) (1,593.85 / 1,594.10) (1,790.7) 26.88 (682.8) 14.13 (358.9) 22.25 (565.2)
Model L R U
Size ATD- J No. - Size M N Q No. - Size S T Min. Max.
SSB 106 0.06
4 - 0.34 (8.6)
4.19 2.69 0.56
2 - 1/4 NPT —
2.00 0.60 2.00
SSB 206 (1.5) (106.4) (68.3) (14.2) (50.8) (15.2) (50.8)
SSB 142 0.25
24 - 1.06 (26.9)
29.50 18.00 1.50
4 - 1/2 NPT
44.13 20.44 8.00 14.00
SSB 242 (6.4) (749.3) (457.2) (26.9) (1,102.9) (519.2) (203.2) (355.6)
SSB 148 0.25
24 - 1.06 (26.9)
32.00 25.75 1.50
4 - 1/2 NPT
52.13 19.00 10.00 18.00
SSB 248 (6.4) (812.8) (654.1) (38.1) (1,324.1) (482.6) (254.0) (457.2)
SSB 260
1
0.25
24 - 4.5" NC
36.00 27.00
— 6 - 1/2 NPT
61.50 20.63 11.00 19.00
SSB 360
1
(6.4) (914.4) (685.8) (1,562.1) (524.0) (279.4) (482.6)
1
Less backplate.
NOTE: For mounting, use socket head capscrews conforming to the ASTM-574-97a.
(Consult factory for drawing before final layout.)
Dimensions: inches (mm)
Dimensions: inches (mm)
