High Power Absorbers
• 15 KW/m² power handling
• Lossy honeycomb
material with
fire-retardant properties
+
Main features
• Honeycomb material allowing free circulation of air
• High heat dissipation through natural convection
or forced air ventilation
• Handles 15 KW/m²; higher power handling
capabilities with forced air
• Withstands temperatures up to 176° C ( 350° F)
• High fire retardancy
Product Configuration
Shape
• Pyramidal
Frequency band
• From 80 MHz to 40 GHz
Standard base size
• 2’x2’ (609 mm x 609 mm)
Height
• 36 in, 24 in, 18 in
• Customizable sizes available upon request
Operating conditions
• Temperature: up to 176°C (350° F)
• Relative humidity: 55% RH +/-15%
Indoor/outdoor
• Indoor
SOLUTION FOR
High energy areas of chambers and equipment
Radar or communications antennas
HPX Series
