Exide Technologies Section 93.30 - Manual (Page 27)

23
Circuit Symbol
(Note 2)
Spare?
(Note 2)
Component Description
R1 Bleeder / Feedback Resistor
R2 Voltage Divider Resistor
R3 B Float Adjustment Potentiometer
R4 Voltage Divider Resistor
R5 B Equalize Adjustment Potentiometer
SCR1 B Silicon-Controlled Rectifier (line 1)
SCR2 B Silicon-Controlled Rectifier (line 2)
SCR3 B Silicon-Controlled Rectifier (line 3)
SH1
DC Ammeter Shunt
(supplied with 50 Adc nominal dc output or greater)
SS1 A, B DC Output Surge Suppressor
SS2 A, B AC Input Surge Suppressor
SW1 B
Standard Manual Float/Equalize Switch
(not supplied when other equalize option provided)
T1 Power Isolation Transformer
TB1 AC Input Terminal Block
TB2 DC Output Terminal Block
TB3
Remote Alarm Terminal Block
(supplied as-required with alarm relay options)
TB5 Internal (+/-) Signal Connection Terminal Block
TB15x
Remote Alarm Terminal Block
(supplied as-required with EJ0837 CASM option)
n/a Wire Harness
n/a Cabinet
n/a Heat Sink(s)
NOTES:
1) "A" indicates recommended start-up spare part
"B" indicates recommended operating spare part
2) For component placement of circuit symbols, refer to Three Phase SCR/SCRF Series
Mainframe Schematic (JE5078-00) on Page 28
3) For mainframe replacement parts, refer to Section IX starting on Page 53
