Electrical ratings and replacement parts – Exide Technologies Section 93.20 User Manual
Page 57
53
ELECTRICAL RATINGS AND REPLACEMENT PARTS
SCR/SCRF Series Battery Charger (Single Phase Mainframe)
PLEASE CONTACT YOUR SALES REPRESENTATIVE FOR DATA ON MODELS NOT LISTED.
SCR/SCRF BATTERY CHARGER MODEL
12V-6A
12V-12A
12V-20A
12V-25A
24V-6A
24V-12A
24V-25A
24V-50A
24V-75A
Enclosure Type
Style-1A
Style-1A
Style-1A
Style-1B
Style-1A
Style-1A
Style-1B
Style-1B
Style-2
AC INPUT CURRENT
(MAXIMUM)
120Vac
240Vac
480Vac
2.6
1.3
.7
3.8
1.9
.9
6.0
3.0
1.5
7.5
3.8
1.9
5.7
2.8
1.4
8.8
4.4
2.2
16
7.4
4.7
26
13
6.5
39
19
9.7
SYMBOL DESCRIPTION
MANUFACTURER'S PART No.
C1/C2
FILTER CAPACITOR
RP0019-01
C3
SNUBBER
CAPACITOR
RP0023-00
CB1
AC INPUT
CIRCUIT BREAKER
120Vac
208-240Vac
380-480Vac
RE0015-03
RE0015-03
RE0015-03
RE0015-03
RE0015-03
RE0015-03
RE0015-04
RE0015-03
RE0015-03
RE0015-04
RE0015-04
RE0015-04
RE0015-04
RE0015-03
RE0015-03
RE0015-04
RE0015-03
RE0015-03
RE0015-06
RE0015-04
RE0015-03
RE0015-09
RE0015-06
RE0015-04
RE0015-12
RE0015-07
RE0015-05
CB2
DC OUTPUT
CIRCUIT BREAKER
RE0015-24 RE0015-25 RE0015-26 RE0015-28 RE0015-24 RE0015-25 RE0015-28 RE0015-34 RE0015-36
CR1
POLARITY DIODE
RK0010-02 RK0009-02 RK0009-02 RK0009-02 RK0010-02 RK0009-02 RK0009-02 RK0017-04 RK0017-04
CR2
BLOCKING DIODE
RK0010-02 RK0009-02 RK0013-02 RK0013-02 RK0010-02 RK0009-02 RK0013-02 RK0017-04 RK0017-04
CR4 -
CR6
RECTIFIER DIODE
part of SCR1/SCR2
F1/F2
DC FUSE
RE0001-19 RE0001-20 RE0001-22 RE0003-01 RE0001-19 RE0001-20 RE0003-01 RE0004-06 RE0004-09
XF1/
XF2
DC FUSEHOLDER
RE0013-00 RE0013-00 RE0013-00 EI0053-00 RE0013-00 RE0013-00 EI0053-00
EI0068-00
EI0068-00
L1
MAIN INDUCTOR
AP0564-00 AP0564-00 AP0565-00 AP0565-00 AP0564-00 AP0564-00 AP0565-00 AP0481-00 AP0808-00
L2
FILTER INDUCTOR
AP0564-00 AP0564-00 AP0565-00 AP0565-00 AP0564-00 AP0564-00 AP0565-00 AP0481-00 AP0314-00
M1
DC OUTPUT
AMMETER
RB0003-01 RB0003-02
RB003-04
RB003-04
RB0003-01 RB0003-02
RB003-04
RB0003-06 RB0003-07
M2
DC OUTPUT
VOLTMETER
RB0002-01
RB0002-02
R1
BLEEDER /
FEEDBACK RESISTOR
RJ0035-27
RJ0022-02
R2
VOLTAGE DIVIDER
RESISTOR
RJ0003-98
RJ0004-12
SCR1 -
SCR2
SILICON-CONTROLLED
RECTIFIER MODULE
RM0002-01 RM0002-01 RM0001-00 RM0001-00 RM0002-01 RM0002-01 RM0001-00 RM0001-01 RM0001-01
SH1
DC AMMETER SHUNT
-
-
-
-
-
-
-
RB0008-01 RB0008-02
SS1
DC OUPUT SURGE
SUPPRESSOR
RK0031-00
SS2 -
SS4
AC INPUT SURGE
SUPPRESSOR
120Vac
208-240Vac
380-480Vac
RK0031-00
RK0038-00
RK0038-01
T1
POWER ISOLATION
TRANSFORMER
120/220/240
Vac
480Vac
AA0650-00
AA0651-00
AA0652-00
AA0653-00
AA0654-00
AA0655-00
AA0654-00
AA0655-00
AA0656-00
AA0657-00
AA0656-00
AA0657-00
AB1250-00
AB1251-00
AB1540-00
AB1542-00
AB1256-00
AB1257-00
TB1
AC INPUT
TERMINAL BLOCK
RC0006-01 RC0006-01 RC0006-01
RC0012-00
RC0012-01
RC0006-01 RC0006-01
RC0012-00
RC0012-01
RC0012-00
RC0012-01
RC0014-00
RC0014-01
TB2
DC OUTPUT
TERMINAL BLOCK
RC0006-00 RC0006-00 RC0006-00
RC0012-00
RC0012-01
RC0006-00 RC0006-00
RC0012-00
RC0012-01
RC0014-00
RC0014-01
FB0313-00
PARTS COMMON TO ALL SINGLE PHASE SCR/SCRF SERIES CHARGERS
SYM
PART NO.
DESCRIPTION
SYM
PART NO.
DESCRIPTION
A1
GK0058-81
CONTROL MODULE PC BOARD (UNFILTERED)
R4
RJ0003-84
VOLTAGE DIVIDER RESISTOR
A1
GK0058-82
CONTROL MODULE PC BOARD (FILTERED-ELIMINATOR)
R5
RJ0014-06
EQUALIZE ADJUSTMENT POTENTIOMETER
C6
RP0043-20
SUPPRESSION CAPACITOR (24/48/130 VDC)
SO1
EJ0617-00
PLUG FOR A1 PC BOARD
C6
RP0046-12
SUPPRESSION CAPACITOR (260 VDC)
SW1
RD0001-00
MANUAL FLOAT/EQUALIZE SWITCH
DS1
RA0001-05
"AC ON" INDICATOR
XA#
EJ0616-00
PC BOARD HOLDERS
R3
RJ0014-06
FLOAT ADJUSTMENT POTENTIOMETER
XC#
PE0068-00
FILTER CAPACITOR BRACKET
TO ORDER PARTS, PLEASE CONTACT YOUR SALES REPRESENTATIVE.
PLEASE ORDER BY QUANTITY, PART NUMBER AND CIRCUIT SYMBOL FROM TABLES ABOVE.
HAVE YOUR BATTERY CHARGER MODEL NUMBER AND SERIAL NUMBER AVAILABLE.
