Adaptor cable, Valco instruments co., inc, Svi to 2pos micro – VICI SVI User Manual
Page 19: Technical drawings
15
BRIAN BOGUE
10/06/95
23196
SVI
23196
1:1
ADAPTOR CABLE
SVI TO 2POS MICRO
I-23196
BLACK OR GREEN
GRAY OR ORANGE
BLUE OR BROWN
WHITE OR YELLOW
VIOLET OR RED
A
NEW DWG ECN# 2801
10/06/95
J.DURR
ITEM
DESCRIPTION
VALCO#
QTY.
SHELL, 10 POSITION .1" AMP
1
I-T102241-8
I-T03061062
CONN 6 PIN MALE MOLEX
2
I-W-R/20
CABLE, RIBBON, 20 COND. 28 GAUGE
3
1
1
1
4
TERMINAL, FEMALE, MOLEX
I-T02061132
5
PIN: CONTACT, AMP
5
I-T187756-6
5
1
5
3
4
2
BLACK OR GREEN WIRE PIN#: 1
1'
AMP PIN#
MOLEX PIN#
1=WHITE OR YELLOW
1=BLACK OR GREEN
2=N/C
2=GRAY OR ORANGE
3=WHITE OR YELLOW
3=BLACK OR GREEN
4=GRAY OR ORANGE
4=BLUE OR BROWN
5=VIOLET OR RED
5=VIOLET OR RED
6=BLUE OR BROWN
6=N/C
7,8,9,10=N/C
NOTE:
RIP 1 PIECE OF 20 CONDUCTOR
RIBBON CABLE INTO 4 PIECES
5 WIRES EACH FOR BOTH COLOR SETS
LTR
DESCRIPTION
DATE
INITIATED
.XXX.005
.XX.01
.X.1
+-1/64"
TOLERANCES UNLESS
OTHERWISE SPECIFIED
DEC.
FRACTIONS
DRAWING NO.
A
THIS DOCUMENT AND THE INFORMATION WHICH IT CONTAINS SHALL NOT BE USED, EXPLOITED OR SOLD, AND SHALL NOT BE REVEALED OR DISCLOSED TO OTHERS
WITHOUT THE EXPRESSED WRITTEN PERMISSION OF VALCO. THIS DOCUMENT SHALL REMAIN THE PROPERTY OF VALCO AND SHALL BE RETURNED UPON DEMAND.
DATE
DESIGNED
DRAWN
SCALE
FILE NAME
SUB-DIR
APPROVED
SHEET
OF
USA
O
+- 1
Valco Instruments Co., Inc.
ANGLES
63
Technical Drawings
