Page -19- CLARKE TECHNOLOGY Nap Sac Operator's Manual
CLARKE TECHNOLOGY
Nap Sac Vacuum
Assembly Parts List 5/99
Standard Highpower
Ref. Part No. Description Qty
1 36210B Lid, Tank Inlet 1 x
1 36211B Lid, Tank H.P. 1 x
2 34279A Gasket, Lid 2 x x
3 34708A Harness Asm. 1 x x
4 38819B Tank, Housing 1 x x
5 34208B Gasket, Vac Motor 1 x x
6 44900A Vac Motor 120V Std. 1 x
44901A Vac Motor 230V Std. 1 x
44902A Vac Motor 230V HP 1 x
44904A Vac Motor 120V HP 1 x
7 64225A Plate, Bottom 1 x x
8 962968 Screw, 10-24 x ½ 16 x x
9 51612A Bumper 4 x x
11 33710A Filter, Exhaust 1 x x
12 53418A Spring, Compression 1 x
13 68640A K Screen 1 x x
14 33709A Filter, Vac Motor 1 x x
15 61528A Bag, Paper Filter (6 pack) 1 x x
16 920065 Nut, 8-32 Nylock 2 x x
17 55717A Latch, Draw 1 x x
18 962992 Screw, 8-32 x 5 /
8
2 x x
19 81507A Pushnut 3 /
16
2 x x
20 66546A Pin, Hinge 1 x x
21 170686 Nut, ½ Conduit 1 x x
22 85397A Screw, 10-24 x 3/8 1 x x
23 42245A Cordset, 16-3 50 ft. 1 x x
40029A Cord Assembly (CE) 1 x x
24 56459A Strain Relief 1 x x
58013A Strain Relief (CE) 1 x x
25 47316B Switch 1 x x
26 34010A Frame, Shoulder 1 x x
27 34011A Frame, Belt 1 x x
28 920328 Nut, 10 x 24 6 x x
29 40028A Filter Assembly (CE) 1 x x
30 60067A Filter Bracket (CE) 1 x x
31 40030A Insulator (CE) 1 x x
32 603642 Screen (CE) 1 x x
33 962546 Screw (CE) 4 x x
34 52789A Cover (CE) 1 x x
35 980603 Lockwasher (CE) 4 x x
36 40031A Terminal FIFQD(CE) 2 x x
*10618A Kit, HEPA Filter (available option)
(included 79027A Instruction Sheet)
*61534A Cloth Filter Bag (available option)
NOTE: K indicates a
change has taken place
since last publication of
this manual
