Illustrated parts breakdown – Vermont Casting ANSI Z83.7-2000 User Manual
Page 10
Page 9
ITEM
NO.
DESCRIPTION
QTY.
PART NUMBER
REMARK
RMC-FA40DLX/
RMC-FA40A/RMC-FA50A
1
OUT SHELL
1
CFM40.01
2
HANDELASSEMBLY
1
CFM40.10
3
SCREW
2
M5X10
4
MOTOR ASSEMBLY
1
CFM40.09-02
4-1
FAN
1
CFM40.05-01
5
SCREW
4
ST3.9X8
6
SUPPORT MOTOR
1
CFM40.06-02
7
SUPPORT MOTOR SCREW
2
M6X15
8
MOTOR BRACKET
1
CFM40.06-01
9
MOTOR CONDENSER
1
CFM50.09-03
10
SCREW
1
M4X8
11
GUARD FAN
1
CFM40.08
12
POWER CORD
1
CFM40.09-01A
13
PCB ASSEMBLY
1
3TH0001
13-1
SCREW
1
ST4.2X10
14
LEAD WIRE ASSEMBLY
1
CFM40.09-03.01A
15
CONNECTOR INLET
1
CFM40.13
16
BASE LOWER
1
CFM40.02-03
17
VALVE
1
CK-890SL-A1(A)
17-1
VALVE KNOB
1
CFM40.11
18
SCREW
4
ST3.9X8
19
BASE ASSEMBLY
1
CFM40.02
20
SCREW
4
ST4.2X10
21
WING BOLT
1
CFM40-M6X12
22
SCREW
1
ST4.2X10
23
HEIGHT CONTROLLER
1
CFM40.02-04
24
SHELL IN ASSEMBLY
1
CFM40.03
25
FLAME HOLDER
1
CFM40.03-02
26
NOZZLE
1
CFM40.12-01
27
THERMAL SWITCH BRACKET
1
CFM40.07-02
28
SCREW
1
ST4.2X10
29
SCREW
1
ST2.9X6
30
THERMAL SWITCH
1
CFM50.09-06
31
NOZZLE NUT
1
CFM80.00-07
32
THERMOCOUPLE
1
1130/1395C-180
33
THERMOCOUPLE BRACKET
1
CFM40.07-01
34
SCREW
1
ST4.2X10
35
SPARK PLUG
1
CFM40.09-04
36
SPARK PLUG BRACKET
1
CFM80.00-04
37
SCREW
1
ST4.2X10
38
TUBING ASSEMBLY
1
CFM40.12
39
SCREW
3
ST4.2X10
40
SCREW
6
ST3.9X8
41
REGULATOR ASSEMBLY
1
TYQ-9C
ILLUSTRATED PARTS BREAKDOWN
