MAGNUM 620D PUMP OPERATION / MAINTENANCE MANUAL PAGE 15
4.5 PARTS LIST
ILL
NO PART NO QTY DESCRIPTION PM
YEAR #
MATERIAL
1 AW100 1 Detent Cap PP
2 AW022 1 Detent Cap Seal PTFE
3 AM068 1 Shuttle Spool Assembly Ceramic, PEEK,
Delrin
4 AW023 1 Shuttle Locking Ring PTFE
5 AK058 1 Shuttle Sleeve Assembly Ceramic, PTFE
6 AW098 1 Master Head PP
AK123 1 Smart Pilot Assembly (INCLUDES 7-11) 1 PEEK/PTFE
7 W0117 2 Pilot Sleeve Seal PTFE
8 98002987 2 Pilot Button PTFE
9 W0099 2 Pilot Sleeve PEEK
10 98002302 2 O-Ring FKM
11 W0122 2 Wear Resist Pilot Piston PEEK
12 W0116 2 Pilot Cap Seal PTFE
13 W0114 2 Pilot Cap PP
15 C0136 4 Check Muffler Pad (Media) 1 PP
16 AW037 1 Check Muffler Spool PP
17 AW105 2 Diaphragm 2 PTFE
18 C0095 2 Push Plate PTFE
19 AM064 1 Shaft 2 PFA
20 98003322 2 Shaft seal 2 PTFE
21 98003395 4 Transfer Tube Fitting PP
22 98001072 2 3/8” Tube PFA
23 AW001 1 Body PTFE
24 98002334 4 O-ring, PTFE Check Valve 2 PTFE
25 98001415 4 Check Ball 2 PTFE
26 AM060 2 Suction Sleeve PTFE
27 AM061 2 Discharge Sleeve PTFE
28 AM083 2 Check Cap Seal 2 PTFE
29 AW003 2 Check Bore Cap PTFE
30 AW014 1 Damper Port Cap PTFE
31 AW017 3 Damper and Adapter Port Seal PTFE
32 AW099 1 Slave Head PP
33 AW057 1 Base, Quick Release PP
34 98003207 4 Base Mounting Screw PP
35 98003071 1 Lever Mounting Screw PP
36 AM023 1 Base Locking Lever PP
37 C0102 1 Base PP
4.6 CLEAN-UP
To help remove potentially dangerous chemicals prior to service or shipment, the
pump should be flushed with DI water or disassembled and thoroughly cleaned.
Allow DI water to flush through the inlet and out the outlet to prevent pressure
build up.
CAUTION: When handling pump, wear appropriate personal protection
gear, including safety glasses.
