tekmar 004 Relay User Manual

Installation & operation manual, D004, Introduction features

background image

Relay 004 - 120 V (ac) Coil

Installation & Operation Manual

D004

05/11

Accessories

Replaces:01/10

1 of 4

© 2011

D 004 - 05/11

The tekmar Relay 004 - 120 V (ac) is for
use in applications where device opera-
tion requires a voltage that differs from
the control’s built-in inputs or outputs.
They can also be used in applications
where the device operation requires a
higher current than the on board relay
is rated for.

Relay 004 is energized with 120 V (ac)

Introduction

Features

Test button
Red LED indicator
Pluggable base



Benefi ts

Mounts to TS35 DIN Rail
Pre-wire and test base before
plugging in relay
Replace relay without disturbing
wiring


Note

For 24 V (ac) coil relay see D003
