Step 4:
Step 5:
Connect the appropriate cables to the 3.5’’ enclosure. Make sure
the polarity of the AC-DC 12VDC power supply is correct. If the
1) Connect the
“Green” LED
connector to D2
location
2) Connect the
“Red”
LED
connector to D1
location
Make sure the
wires are properly
aligned when
closing the rear
cover. Secure the
rear cover with the
screws provided.
