30
Fitting the Adjustable Feet
– The adjustable feet must be fitted to the base of the cooker before use.
– Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of
the feet.
– Fit the 4 legs by screwing them tight into the support base as shown in picture 32.
WARNING
When raising cooker to upright position always ensure two people carry out this manoeuvre
to prevent damage to the adjustable feet (fig. 34).
Fig. 33
Assembling the Backguard
– Remove the two spacers “A” and the
screw “B” from the rear of the cooktop.
– Assemble the backguard as shown in
figure 31 and fix it by screwing the central
screw “B” and the spacers “A”.
A
B
Fig. 31
A
B
Fig. 32
