Page 19: Dn l d d1 h h1 h (stroke)
Series MV/F, MVM/F, MVP/F, MVMP/F
Page 19
9510-050-en
Revision 02
TM 7669
Edition 10/2009
10.10 Dimensional drawing MVM/F
Option safety stuffing box
DN
L
D
D1
H
H1
h (stroke)
Weight
[inch]
[mm]
[inch]
[mm]
[inch]
[mm]
[inch]
[mm]
[inch]
[mm]
[inch]
[mm]
[lb]
[kg]
1“
5.8
(147,5)
4.25
(108)
3.74
(95)
5
(127)
7.2
(183)
0.47
(12)
9.92
(4,5)
1½“
6.89
(175)
5
(127)
6.3
(160)
6.7
(170)
9.02
(229)
0.71
(18)
17.42
(7,9)
2“
7.87
(200)
6
(152,5)
6.3
(160)
6.97
(177)
9.09
(231)
1.06
(27)
24.25
(11)
3“
10.23
(260)
7.5
(190,5)
7.48
(190)
9.13
(232)
12.2
(310)
1.57
(40)
50.71
(23)
4“
12.87
(327)
8.5
(216)
9.06
(230)
9.92
(252)
12.6
(320)
1.57
(40)
67.68
(30,7)
6“
13.38
(416)
11
(279,5)
13.78
(350)
14.76
(375)
17.13
(435)
2.36
(60)
132.06
(59,5)
Flange connecting dimensions:
ASME B16.5 Class 150, raised face
