Revel Performa IC15

Owner’s Manual

SPECIFICATIONS

Specification

IC15

Frequency Range (+

– 3dB)

80Hz – 20kHz

Recommended

10 – 200 Watts

Amplifier Power Range

Sensitivity

85dB

(2.83V @ 1 meter)

Nominal Impedance

8 Ohms

Crossover Frequency

700Hz, 2,000Hz;
24dB/octave

Low-Frequency Driver

7-3/4" x 3-3/8"
(197mm x 85mm)

Midrange Drivers

Dual 3" (75mm)

High-Frequency Driver

1" (25mm)
Pure titanium

External Diameter

Diameter: 12-3/4"
(323mm)

Mounting Cutout Diameter

Diameter: 11-3/8"
(289mm)

Mounting Depth

5-5/8" (142mm)

Weight (Net)

8 lb (3.6kg)

NOTES

Features, specifications and appearance are subject to
change without notice.
