Revel Performa3 C208/C205 Center Channel Loudspeaker
Owner’s Manual
Eng
Lish
sPeCifiCAtions
C208
Type:
3-way dual 8" center channel loudspeaker
Low-frequency transducer:
Two 8" (200mm) aluminum cones, with cast frames
Midrange transducer:
4" (100mm) aluminum cone, with cast frame
High-frequency transducer:
1" (25mm) aluminum dome, with acoustic lens waveguide
Recommended amplifier power range:
50 – 350 watts
Low-frequency extension:
34Hz (–10dB); 41Hz (–6dB); 50Hz (–3dB)
Nominal impedance:
8 ohms
Sensitivity (2.83V/1m):
89dB
Crossover frequencies:
375Hz; 2.45kHz
Enclosure type:
Sealed
Controls:
Low-frequency contour; high-frequency level
Inputs:
Dual gold-plated binding posts with shorting straps
Available finishes:
Piano black, high-gloss walnut
Dimensions (H x W x D):
11-13/16" x 28-15/16" x 13-3/4" (300mm x 735mm x 350mm)
Weight:
51.5 lb (23.4kg)
C205
Type:
2-way dual 5-1/4" center channel loudspeaker
Low-frequency transducer:
Two 5-1/4" (130mm) aluminum cones, with cast frames
High-frequency transducer:
1" (25mm) aluminum dome, with acoustic lens waveguide
Recommended amplifier power range:
50 – 120 watts
Low-frequency extension:
46Hz (–10dB); 62Hz (–6dB); 80Hz (–3dB)
Nominal impedance:
8 ohms
Sensitivity (2.83V/1m):
89dB
Crossover frequencies:
1.7kHz
Enclosure type:
Sealed
Inputs:
Gold-plated binding posts
Available finishes:
Piano black, piano white, high-gloss walnut
Dimensions (H x W x D):
7-7/8" x 21" x 11-1/2" (200mm x 532mm x 292mm)
Weight:
26.1 lb (11.9kg)
