8 Revel Performa3 C208/C205 Center Channel Loudspeaker
Owner’s Manual
oPtimizing PeRfoRmAnCe
C208 Adjustments
As discussed in the C208/C205 Overview section on page 2, the C208 has
Low-Frequency Compensation and Tweeter Level adjustments that allow
you to tailor its performance for your individual listening situation and
personal preferences.
Once you have installed and connected your loudspeaker we suggest
following these steps the first time you turn you new C208 loudspeaker on:
1. Set the Tweeter Level switch to 0. (The control should normally be
left in the default “0” position.)
2. Set the Low Frequency Compensation switch to the appropriate
position.
• Select the Normal setting if the loudspeaker is located at least
3 feet (0.91m) from walls.
• Select the Boundary setting if the loudspeaker is flush-mounted
in an entertainment center or shelving unit or if the loudspeaker
is located less than about 2 feet (0.61m) from walls and other
objects.
CAUTiOn: Do not operate the switch while audio is playing
through the speaker.
3. Begin playback of a familiar film or music source.
4. Listen from the primary listening position, increasing the volume to
a comfortable level.
5. Experiment with the loudspeakers’ placement to achieve the best
overall tonal balance, and spatial integration with the front left
and front right loudspeakers. There should be little tonal change
in a sound as it moves from left to right or right to left. Refer to
the Installation Considerations section on page 4 for additional
information about loudspeaker placement.
6. If necessary, adjust the Tweeter Level switch on the loudspeaker to
change high-frequency balance and timbre to fine-tune the overall
tonal balance with that of the front left and front right speakers.
CAUTiOn: Do not operate the switch while audio is playing
through the speaker.
7. Experiment with the Low-Frequency Compensation switch to
achieve the best low-frequency performance for your particular
listening room and installation.
loudsPeAkeR volume levels
The high-order filters employed in Revel Performa3 series loudspeakers
include steep cut-offs to reduce potential transducer damage from
“out-of-band” frequencies. Combined with carefully selected
transducers and filter network components, this approach helps the
Performa3 floorstanding loudspeakers maintain their performance
under extreme operating conditions.
However, all loudspeakers have limits when it comes to continuous
playback. To avoid exceeding these limits, avoid playback at volume
levels that distort or strain the sound.
CAUTiOn: To avoid damage, reduce volume level
immediately if the loudspeaker sound is not clean and clear.
CARing foR youR loudsPeAkeRs
gRilles
Revel Performa3 center channel speakers feature grilles with a magnetic
attachment method that eliminates unsightly attachment hardware from
the speaker baffle, so if you decide to use your speakers with the grilles
removed they will retain their elegant appearance.
CAbinet finish
The cabinet’s wood veneer finish does not require routine maintenance.
Cabinet surfaces that have been marked with dust, fingerprints, or other
dirt can be cleaned using a soft cloth – preferably micro-fiber, and high
quality auto wax. Take care not to come in contact with the transducers.
Use caution to avoid contacting the rubberized trim on the sides of the
loudspeaker with auto wax. If necessary, the rubberized trim can be
cleaned with denatured alcohol on a microfiber cloth.
To clean the grille, gently vacuum it using a soft-bristled brush vacuum
attachment with the vacuum cleaner set to the lowest possible suction.
CAUTiOn: To prevent cabinet damage, do not use a cloth
made with steel wool or metal polish to clean the cabinet.
To prevent possible transducer damage, do not apply
furniture polish directly to the cabinet.
