10
Key# Description Part # Qty
1 QC
HC Main Casting 7709026 1
2 QC HC Powder Hopper 7109027 1
3 QC HC Powder Hopper Cap 7189028 1
4 QC HC Measuring Cylinder 7798849 1
5 QC HC Metering Screw 7798851 1
6 QC HC Metering Screw Bushing 7798850 1
7 Metering Screw Lock Ring 7709014 1
8 Bow Washer 7109260 1
9 QC HC Drain Tube 7798853 1
10 Handle Assembly 7709027 1
11 Handle Screws 7109019 2
13 QC Locking Pin Assembly 7798856 1
14 7/8"-14 Hex Lock Ring 7109187 1
15 Drop Tube Large .50 cal 7198854 1
16 Drop Tube Small .22-.270 cal 7198852 1
17 Drop Tube Medium .30-45 cal 7198853 1
18 "O" Ring 7138285 6
3
The above warranty provides the sole and exclusive warranty available to the
customer in the event of a defect in material or workmanship in the reloading
press. This warranty gives you specific legal rights, and you may also have other
rights which vary from State to State.
SAFETY
Reloading is an enjoyable and rewarding hobby that can be conducted safely.
But, as with any hobby, carelessness or negligence can make reloading
hazardous. This product has been designed from the beginning with the user's
safety in mind. When reloading, safety rules must be followed. By observing
these rules, the chance of a hazardous occurrence causing personal injury or
property damage is minimized.
GENERAL
• Use all equipment as the manufacturer recommends. Study the instructions
carefully and become thoroughly familiar with the operation of the product. If
you do not have written instructions, request a copy from the equipment
manufacturer.
• Do not take short cuts. Attempting to bypass established procedures is an
invitation to an accident.
• Observe "good housekeeping" in the reloading area. Keep tools and
components neat, clean and orderly. Promptly and completely clean up primer
and powder spills.
• Reload only when you can give your undivided attention. Do not reload when
fatigued or ill, or under the influence of medications or alcohol.
• Develop a reloading routine to avoid mistakes which may prove hazardous. Do
not rush - load at a leisurely pace.
• Always wear adequate eye protection to protect your eyes from flying particles.
You assume unnecessary risk when reloading without wearing safety glasses.
LOADING DATA
• Use only laboratory tested reloading data. We highly recommend the current
SPEER Reloading Manual.
• OBSERVE ALL WARNINGS ABOUT THE USE OF MAXIMUM LISTED
LOADS
WARNING/CAUTION
PRIMERS AND POWDER
• Store primers and powder beyond the reach of children and away from heat,
dampness, open flames and electrical equipment. Avoid areas where static
electricity is evident.
• DO NOT use primers of unknown identity.
• Dispose of unknown primers in accordance with applicable regulations.
• Keep primers in the original factory container until ready to use. Return unused
primers to the same factory packaging for safety and to preserve their identity.
Primer packaging is designed to provide safe storage.
