PRECISIONEERED ® RELOADING EQUIPMENT
We think that we make the very best
reloading equipment in the world.
If you agree, please tell your friends.
If you disagree, tell us - we want to do something about it!
Customer Service
1-800-533-5000 (US or Canada) or 530-533-5191
Hours: Monday - Friday, 6:30am - 4:00pm Pacific Time
e-mail: [email protected] • www.rcbs.com
RCBS • 605 Oro Dam Blvd. • Oroville, CA 95965
CCI • SPEER • RCBS
OUTERS • RAMLINE • ORBEX • FEDERAL
201279/0404
IMPORT ANT: READ THIS SECTION FIRST
Before using the RCBS T urret Press , read the instruction man ual carefully to fully learn ho w to safely
operate the related reloading equipment. Failure to proper ly operate cer tain reloading equipment can
result in severe personal injur y and/or equipment damage. If you ha ve read these instructions and still
do not understand some operation, call us at 1-800-533-5000 and a technician will assist y ou.This
instruction man ual contains specific safety and oper ating infor mation.It should be considered a per ma-
nent part of y our reloading equipment and remain with the equipment at all times for easy ref erence.
SAFETY
Reloading is an enjoya ble and re warding hob by that can be conducted safely .But, as with an y hobb y ,
carelessness or negligence can make reloading hazardous .This product has been designed from the
beginning with the user’s saf ety in mind.When reloading, saf ety rules m ust be follo wed. By observing
these rules , the chance of a hazardous occurrence causing personal injury or proper ty damage
is minimized.
GENERAL
•Use all equipment as the man ufacturer recommends .Study the instr uctions carefully and become
thoroughly familiar with the oper ation of the product.If y ou do not have written instr uctions, request a
copy from the equipment man ufacturer .
•Don’t tak e short cuts .Attempting to b ypass established procedures is an in vitation to an accident.
•Obser ve “good housek eeping”in the reloading area. Keep tools and components neat, clean and
orderly .Promptly and completely clean up pr imer and powder spills .
•Reload only when y ou can give y our undivided attention.Do not reload when f atigued or ill, or under
the influence of medications or alcohol.De velop a reloading routine to a void mistak es which may
prove hazardous. Don’t rush - load at a leisurely pace .
•Alw ays w ear adequate eye protection to protect your e yes from flying par ticles.Y ou assume
unnecessary r isk when reloading without wear ing safety glasses .
LOADING DAT A
•Use only labor atory tested reloading data. We highly recommend the current SPEER Reloading
Manual.
•OBSER VE ALL W ARNINGS ABOUT THE USE OF MAXIMUM LISTED LO ADS.
PRIMERS AND POWDER
•Store pr imers and powder be yond the reach of children and a wa y from heat, dampness , open flames and
electrical equipment. Avoid areas where static electr icity is evident.
•Do not use pr imers of unknown identity .Scr ap unknown pr imers in accordance with applicable
regulations.
•K eep primers in the or iginal factor y container until ready to use.Retur n unused pr imers to the same
factor y packaging f or safety and to preser ve their identity .P rimer pac kaging is designed to provide saf e
storage .
•DO NO T store primers in b ulk.The b last of just a fe w hundred primers is sufficient to cause ser ious injury
to anyone nearb y .
•DO NO T force pr imers.Use care in handling pr imers.
•DO NO T have more than one can of powder on the bench at one time .P owder cans should be stored
aw ay from the bench to a void pic king up the wrong one.
•DO NO T use any po wder unless its identity is positively kno wn.The only positiv e identification is the
manuf acturer’s label on the or iginal canister.Discard all mix ed powders and those of uncertain identity .
•If y ou use a powder measure , replace the lids on both the powder hopper and po wder can after the
powder hopper has been filled.
•When using a po wder measure, settle the po wder in the powder hopper bef ore charging any cases .
Throw and chec k the weight of at least ten charges .This will assure y ou that the correct powder charge
is being thrown.
•When y ou finish a reloading session, pour any remaining po wder back into its or iginal factor y container.
This will preserv e the identity and shelf lif e of the powder .
•DO NO T smoke while reloading.
RECORD KEEPING
• Keep complete records of reloads .Apply a descr iptive label to each bo x showing the date produced,
and the primer , powder and b ullet used.Labels f or this purpose are pac ked with SPEER b ullets.
Never attempt to guess at the identity of y our ammunition.
Because RCBS has no control over the choice of components , the manner in
which they are assemb led, the use of this product, or the guns in which the
resulting ammunition ma y be used, we assume no responsibility , e xpressed
or implied, for the use of amm unition reloaded with this product.
P R O D U C T I N S T R U C T I O N S
TURRET PRESS
ACCESSORIES
Uniflow Powder Measure 09010
Features an adjustable cylinder. Iron and steel construc-
tion ensures long life and accuracy. See photo 10.
Case Activated Linkage Kit 98911
It automatically activates dispensing a charge with every
pull of the handle only when a case is present under the
Uniflow Powder Measure. See photo 11.
Lock Out Die 87540
The Lock-Out Die detects a “no powder” or a
“double charge” condition in the progressive reloading
process. See photo 12.
Powder Checker Die 87590
A simple, effective way to visually check powder charges
before seating a bullet when you use a
progressive press. Shows low and high charges.
See Photo 13.
Lube Die
Decaps and lubes cases in one step. Eliminates time and
mess associated with lubing cases. Four sizes cover 45
popular calibers. Refer to our RCBS Catalog for a com-
plete list of caliber sizes. See Photo 14.
Universal Decapping Die 87580
Quickly removes primers from case before cleaning.
Handles calibers 22 through 45. See photo 15.
Precision Mic 09440
Accurately reads your chamber headspace and bullet
seating depth to 0.001 of an inch. See photo 16.
Micro Pro Scale 86040
This new sleek scale is compact, lightweight and
portable. Option of AC powered or 9v battery.
See photo 17.
13
16
11 10
14
12
15
17
RCBS TURRET PRESS
The new RCBS T urret Press no w gives y ou a choice between single stage or
progressiv e reloading.With Dies pre-set in the turret, y ou can increase your output from 50
to 200 rounds per hour with the turret.Dies can be left in the turret to eliminate teardo wn
and set-up.The T urret handle is also used to remo ve the turret head, eliminating the need
for other tools .The T urret Head e xchanges easily with the removal of one bolt (a 3/4" soc ke t
can be used).This press is co vered b y the RCBS Lif etime W arranty .If it e ver breaks or does-
n’t wo rk, w e will fix it or replace it free .No time limit, no questions ask ed and no fine print.
RCBS TURRET HEAD QUICK CHANGEOVER
The RCBS Turret Head mak es it easy to maintain your die set-up
while you change calibers b y using our quic k change turret heads.
RCBS TURRET HEAD
The RCBS Turret Head is made to accept standard 7/8”-14
threaded reloading dies, with no b ushings or adapters required.
The dies and/or RCBS Uniflow P owder Measure can no w be
mounted.The instr uctions for the use and set-up of the reloading
dies and other accessories come pac kaged with these items.Y ou
will find through exper imentation that many m ultiple combinations
can be obtained in the mounting sequence of dies and powder measures ,
permitting tw o or more calibers to be set up at the same time.
UNPACKING
Unpack the press carefully and look f or the follo wing
items listed below .Ref er to the parts list
for identification.
•Press F rame Assemb ly
•Handle
•P rimer T ube Large
•P rimer T ube Small
•P rimer T ube Assemb ly Large
•P rimer T ube Assemb ly Small
•Saf ety T ube
•P rimer Catcher
•Bag #1:
Primer Dispenser Assemb ly
•Bag #2
8-32x1/2”SHCS (T wo)
Primer Plug Large
Primer Plug Slee ve Large
Primer Plug Spr ing (One)
Hex K eys 3/32 & 9/64 (One each)
T urret Pin Assemb ly
Safety T ube/
Primer Tubes
Turret
Reloading Dies
Shell Holder
Primer
Dispenser
Handle
To ggleb lock
Primer
Catcher
