Knog NERD 9 - Manual (Page 10)

10
MAIN UNIT (Fig 3.1)
The main computer unit is designed with a removable and
rotatable main housing for mounting to handlebars or a
handlebar stem. The silicon strap makes the installation on
a bike super easy and fast.
1. Chose a suitable location on your handlebars (
1 ) or
stem ( 2 ) that will enable a good line of sight down to
the transmitter and the main unit with minimal physical
obstructions.
2. Pull the silicon strap around the bars, fit it over the hook
and you’re done!
The silicon strap on the main computer is designed to
accommodate mounting diameters of 22mm up to 38mm.
For optimum wireless signal clarity your N.E.R.D. should
be positioned 5cm (2 inches) away from your white bike
light.
BIKE INSTALLATION
Fig 3.1
* = N.E.R.D Wireless 12 Function Cycle Computer only
