5
Each filter holder ( FIL-KAM6) has
a detent on one side of the frame.
To properly secure the holder, the
detents should align with the two small
pushball set screws on the tray (1).
The tension can be adjusted by
using a flat jeweler’s screwdriver (1)
to vary the depth of the screw set-
ting. The silver thumbscrews (2) lock
the filter trays in position. The Lens
Clamp (3) locks the Kamio to the lens.
Changing Lamps
Extract the lamp by pushing the
lamp harness through the reflector.
The lamp will clear the reflector
making it easier to grasp.
The Filter Tray holds a maximum of
two 4 x 5.65” filter holders or
two 4 x 4” filter holders.
