The Blanket-Lite consists of four wiring
harnesses that power sixteen, 6ft HO
lamps. You must follow the color-coding to
achieve light level control features
(discussed in Ballast section).
Note: The easiest way to mount lamps is if
the Blanket-Lite Ratchet straps have
already been attached to the Frame. Velcro
loops hold lamps to the straps.
Important!
The color-code on both ends of the lamp
must be the same, and both ends must be
securely connected BEFORE turning on
power. Once the lamps have been loaded,
they can stay attached to the Blanket-Lite
and placed in the Shipping Case for storage
and shipping. If a second color temperature
lamp is used regularly, it is recommended
to have an additional pre-globed Blanket-
Lite and an additional shipping case.
X19-
12M
Mega 4Bank
Ext. Cable 12ft
DFS-6X6/G
Full Grid Cloth
Diffuser
MTP-BKT-100
Frame Ear
MTP-BKT-300
Frame Clip Pin
DFS-6X6/GH
Half Grid Cloth
Diffuser
LVC-6X6
Lighttools ® 50°
Louver
