Kino Flo VG4R Ballast Board - Manual (Page 4)

Environmental: Disposal of Old Electrical & Electronic Equipment.
This symbol on the product or on its packaging indicates
that this product shall not be treated as household waste.
This product is made of recyclable materials and should be
disposed of in accordance with local and state regulations
Kino Flo, Inc. 2840 N. Hollywood Way, Burbank, CA 91505, USA
Tel: 818 767-6528 website: www.kinoflo.com
4
Ballast Board Removal Ballast Board Installation
1) Remove ten (10) cover screws. 4) Install new ballast board and
three (3) nuts.
2) Remove AC input, output,
remote and HO/Std connector
and three (3) nuts.
3) Remove ballast board. 6) Install ten (10) cover screws.
Image 85 DMX (IMG-85X-120)
is shown for illustration purposes.
5) Install AC input, output, remote
and HO/Std connector.
