5
The BAL-139X power connection is a
4-Pin XLR connector.
Note: Use external power supply (PWS-1524X)
to operate on 100-250VAC.
1) Turn dimmer up to full.
2) Insert the lamp harness connector into the
receptacle on the ballast.
3) Turn on the power switch.
4) The dimmer knob will adjust the light level.
Kit Components & Lamps
CFX-091 9” Mini-Flo Fixture
CFX-1201 12” Mini-Flo Fixture
X02-12S Mini-Flo Extension, 12ft
BAL-139X Mini-Flo Ballast (4-Pin XLR),
12VDC
MTP-MW6 Mini-Flo Flex Arm Coil, 6ft
MTP-MM Mini-Flo Flex Arm Mount
