Fixture Assembly
Inserting Lamps
3
Fixture is comprised of 3 parts:
•
Lamp Harness
•
Fixture Shell
•
Black Louver
The Lamp Harness, Fixture Shell and Louver are held together with
Velcro fasteners.
Insert the pins at both ends of the lamp into the
lamp holder. Rotate the lamp a ¼ turn until the
lamp clicks into place.
