11. KN6 TECHNICAL DETAILS
KN6
Acoustics
Power handling 2x250 + 3x20 w (AES)
Maximum
amplifier power
2x500 + 3x40 w (EIAJ)
Impedance 2x4Ω + 3x16Ω
Operating
frequency range
45Hz - 19 KHz +/- 3dB (preset dependent)
SPL 1W/1mt 96 dB (low) 104 dB (high)
Maximum SPL 125 dB continuous - 131 dB peak
Coverage (in horizontal position)
Horizontal 130°
Vertical selectable from 10° to 130°
Crossover
Type DSP controlled
Frequency 1.8 KHz minimum (preset dependent)
Transducers
Low - Mid frequency 2 x 6” Neodymium speakers with 2.5” voice coil
High frequency 3 x 0.5” Neodymium compression driver with 1” voice coil
Audio Input
Connectors male + female parallel 3-pin balanced XLR
Wiring PIN1= ground PIN2 = hot (+) PIN3 = cold (-)
Power Input
Connectors 1 x 3-pin PowerCon
Amplifiers
Type
2 x 250W class D amplifier channel - DSP controlled
+ 2 x 20W class A/B amplifier channel
Power (woofer) 350 + 350 Watt 1
Power (driver) 2 x 40 Watt 1
Protection Dynamic limiter, over current, over temp, short circuits
AC power
Operating range 85 - 270 Vac 50/60Hz autorange
Max continuous
and burst current
140VA(>10 sec) - 700VA (<1 sec) autorange
Physical
Dimensions 19 x 50.5 x 17.5 cm (7.48”x 19.88”x 6.89”)
Weight 9 Kg (19.84 lbs)
Notes for data
1. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS
voltage that the amplifier will produce into the nominal load impedance .
New materials and design are introduced into existing products without previous
notice. Present systems may differ in some respects from those presented in this
brochure.
rev.A
