innkeeper PBX™

VOIP/PBX Desktop Digital Hybrid

Technical Information

Input

Impedence / Level

Female XLR (2) Mics

1k ohms / 15 mV RMS; -34 dBu nom.;

Mic/Line Pad Switch = +6 dBu max

1/8” (3.5mm) Stereo Line

20k ohms / 250 mV RMS; -10 dBu nom.

Output

Balanced Male XLR

200 ohms / 500 mV RMS; -4 dBu nom.;

+14 dBu max; Caller Only

1/8” (3.5mm) Stereo

50 ohms / 250 mV RMS;

-10 dBu nom.;

+6 dBu max

Left = Send; Right = Caller

Headphone 1/4” Stereo

8 ohms / 250 mW

Mixed Send and Caller

Phone Line Connector

RJ22

Isolation

1500 VAC

Frequency Response

Telephone Side 200 Hz-3600 Hz

Power

120-240 VAC Power Supply

Size

7” x 6” x 1.6” (18 x 15 x 4.2 cm)

Weight

2.2 lbs. (1kg)

Specifications
