12
Concierge™ 2x6
Switch Core
T
echnical Information Phone Lines (6) Connector
RJ-1
1C
Isolation
1500 V
A
C
Ringer
0.5B REN
Hold
Audio Line Input
Connection
3.5mm mono
Impedence
20k ohms
Level
(-10 dBu) nom.
USB Connector
T
ype B
Standard
v2.0
Power Power
120-240 V
AC, 50-60 Hz,
25 W
atts max
Connector
IEC320-C14
Dimensions Size
1.75” x 7.3” x 19” ( 4.5 x 18.6 x 48.3 cm )
W
eight
5.4 pounds ( 2.4 kg )
Overview
1
Introducing the Concierge™ 2x6 The Concierge™ 2x6 switch core allows connection of two hybrids across six phone lines.
The switch matrix routes six incoming analog phone lines to either
one or two JK
Audio innkeeper 1rx™ single channel Digital Hybrids, or one
innkeeper 2™ Digital Hybrid.
A
fi
rmware upgrade is all that is required to make
most older model INN 1x/INN 1rx and INN 2 hybrids compatible with this new system. See page 1
1
for innkeeper compatibility
.
Concierge adds music on hold input, auxiliary phone integration, and intuitive call control.
The end result is a powerful,
fl
exible system featuring excellent call
screening capabilities, while allowing two studios to share the phone lines. T
wo Concierge switch cores can be bridged together
, providing six additional
phones lines for a 2 hybrid, 12 line system. Up to eight Guest Module control surfaces can be added to provide remote control of the switch matrix over CA
T5 cable. Guest Modules are hot swappable
without losing calls, and feature line selection buttons that change color to indicate call status. Guest Modules are available in GM1x6, GM2x6, and GM1x12 desktop and rack mount versions. The smallest system consists of one Concierge switch core, one innkeeper 1rx, and one Guest Module GM1x6 control surface. 6 Phone Line jacks 2 Hybrid Connections Hold Audio
Input
Expandable to 2 x 12 Lines
LED Line Status Indicators Front panel DIP
Switches
Auto-Ring &
Auto-Drop Controls
Overview
