Brinkmann 2500 User Manual
Page 26
25
Step 11
Attach side burner igniter lead to
the electrode as illustrated.
Step 12
Attach side table assembly to grill
body assembly by inserting four
M6 X 20mm bolts halfway into the
screw holes of the grill body
assembly. Then slide side table
assembly onto bolts and secure all
four bolts.
Side Table
Screw Holes
Gas Hose
Side Burner Igniter
Lead
Electrode
Brass Nut
