Brinkmann 2500 - Manual (Page 18)

ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this Brinkmann Pro Series 2500 Grill:
• Flathead Screwdriver
• Hex Nut Wrench
17
1 Back Cart Panel
1 Side Burner Knob
1 Left Side Cart Panel
1 Right Side Cart Panel
1 Bottom Cart Panel
2 Doors
4 Locking Casters
2 Door Magnets
2 Door Handles
PARTS LIST:
1 Hood
1 Hood Handle
1 Warming Rack
2 Cooking Grills
2 Heat Shields
1 Grill Bottom
4 Grill Burners
1 Grill Body Assembly
1 Grease Tray
1 Grease Tray Bracket
4 Control Knobs
1 Temperature Gauge
1 Side Burner Grate
1 Door Bracket
1 Electronic Igniter Button
1 Electronic Igniter Spring
1 Brass Burner Ring
1 Side Burner Assembly
1 Side Shelf
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
25
26
27
20
28
