Gossen Mavomonitor - Manual (Page 2)

2 GOSSEN Foto- und Lichtmeßtechnik
1 Display
2 Slider switch cd/m² – segment test
3 ON/OFF switch
4 Rechargeable battery socket
5 Socket for recorder output
6 Hold key
7 Selector slider switch
8 Socket for connection to meas. sensor
9 Measuring sensor
10 Sensor aperture
Contents Page
1 Description of MAVO-MONITOR ............. 3
2 Applications .............................................. 3
3 Operating the MAVO-MONITOR .............. 4
3.1 Inserting the Battery ........................................4
3.2 Preparing the Measurement ............................4
3.3 Contact Measurements ...................................5
3.4 Overflow ..........................................................5
4 Functioning and Circuitry ........................ 6
5 What is Luminance? ................................ 6
6 Technical Data .......................................... 7
7 Maintenance .............................................. 8
7.1 Calibration Service ..........................................8
7.2 Cleaning and Maintenance ..............................8
8 Description of MAVO-SPOT ..................... 9
9 Operating the MAVO-SPOT ................... 10
9.1 Inserting the Battery ......................................10
9.2 Battery Control ...............................................11
9.3 Preparing the Measurement ..........................11
9.4 Measuring ......................................................11
10 Technical Data ........................................ 12
11 Maintenance ............................................ 13
11.1 Calibration Service ........................................13
11.2 Cleaning and Maintenance ............................13
1
7
6
8
2
3
5
9
10
4
