GBC 65-1 Ultima - Manual (Page 69)

65
GBC Films Group
4151 Anderson Road, DeForest, WI 53532
This print is the property of GBC Films Group. The information thereon is remitted in confidence.
UNLESS OTHERWISE SPECIFIED
TOLERANCE
DIM. AS
SHOWN TOL.
+ 1/64
+ .050
+ .020
+ .010
+ .005
X/X
X
XX
XXX
XXXX
ANGLES
+ 1D
FINISH
TO BE
125
TITLE :
DATE : DRAWN BY : DWG SCALE : DWG :
R
EVI
SI
O N
CHE
CKE
D B
Y : G
BC F
IL
M
S G
R O
U P
OR
IGI
N A T OR
: GM
P
MANUFACTURE OR FOR ANY OTHER PURPOSE WITHOUT WRITTEN
COPIED OR DISCLOSED IN WHOLE OR IN PART, OR USED FOR
FOR ENGINEERING INFORMATION ONLY AND SHALL NOT BE REPRODUCED,
GBC PRO-TECH CLAIMS PROPRIETARY RIGHTS TO THE
MATERIAL DISCLOSED ON THIS DRAWING. IT IS ISSUED IN CONFIDENCE
PERMISSION FROM GBC PRO-TECH
PROPRIETARY
C
Slitter assembly
Ultima 65-1
U651 - 010 N/A N/A 11/27/02
(1) 701110101
Nut, M3
(1) 604022034
Slitter lever
(1) 701104803
Truss head 2 class bolt
(1) 613050221
Slitter blade
(1) 604022033
Slitter blade housing
(1) 701090159
Slitter lever spring
U651-010 SLITTER ASSEMBL
Y
