Page i
Operating Instructions
27C
1. Safety
Warnings ................................................................. 1-1
General .................................................................... 1-1
Electrical .................................................................. 1-2
2. Warranty
Limited 90-Day Warranty ........................................ 2-1
3. Specifications
FCC Note ................................................................ 3-2
4. Installation
Prior to Installation ................................................. 4-1
Installation .............................................................. 4-1
5. Feature guide
Top Film Supply Shaft ............................................ 5-1
Release Liner Take-up .......................................... 5-1
Idler Bar .................................................................. 5-1
Pressure Rollers ..................................................... 5-1
Nip Point ................................................................ 5-1
Safety Shield .......................................................... 5-1
Feed Table .............................................................. 5-2
Table Interlock Latch ......................................... 5-2
Bottom Film Supply Shaft ................................ 5-2
Film Web ................................................................ 5-2
Core Adaptors .................................................. 5-2
Roller Pressure Handle ......................................... 5-2
Film and Take-up Tension Adjustment Knobs ... 5-3
Control Panel ..................................................... 5-3
POWER SWITCH .................................................... 5-4
6. Operation
General Operation .................................................. 6-1
Loading Film ........................................................... 6-2
Removing and Installing the Safety Shield ........ 6-3
Removing and Installing the Feed Table ........... 6-3
Loading Film Onto the Supply Shafts ................ 6-4
Loading Film with a Threading Card ................. 6-6
Loading Film by Tacking New Film to Existing Film
6-7
Decaling in Two Passes ......................................... 6-8
Mounting ............................................................... 6-10
Tips For Threading Pressure Sensitive Adhesive
(PSA) Film .........................................................
6-10
Pre-Treating Boards .......................................... 6-10
Mounting Only .................................................. 6-10
Film Alignment and Tension .................................. 6-10
Film Alignment .................................................. 6-10
Film Tension ...................................................... 6-11
Testing the Web ............................................ 6-11
Clearing a Film Jam (Wrap-up) ......................... 6-12
Lamination Guide ................................................. 6-12
7. Operator Maintenance
Caring for the 27C Laminator .................................. 7-1
Cleaning The Rollers ........................................... 7-1
Troubleshooting ...................................................... 7-2
T
ABLE OF
C
ONTENTS
