Page 5-1
Operating Instructions
27C
T
OP
F
ILM
S
UPPLY
S
HAFT
Holds the film supply on the laminator.
R
ELEASE
L
INER
T
AKE
-
UP
Rewinds the release liner of pressure sensitive films.
I
DLER
B
AR
(Not shown.) The idler bar directs the film to the
roller.
P
RESSURE
R
OLLERS
Two pressure rollers apply pressure to the film and
the print being laminated or mounted. They pull the
print and films into the laminator.
N
IP
P
OINT
(Not shown.) The point at which the top and bottom
rollers come into contact and the point at which the
items for lamination are introduced into the laminator.
S
AFETY
S
HIELD
The safety shield prevents entanglement,
entrapment, and inadvertent contact with the rollers.
When the safety shield is removed, the laminator
runs at 3 fpm (0.9 m) when you press the RUN
button. The safety shield is removed only when you
load films.
WARNING: Keep your fingers and hands away
from the nip point. Failure to observe this warning
could result in severe personal injury.
5. F
EATURE GUIDE
Fig. 5-1. 27C Laminator Identification.
This chapter helps you identify the main components of the laminator.
Safety shield
Feed table
Top film supply shaft
Bottom supply shaft
Release liner take-up
Roller pressure
handle
Feed table
interlock latch
(under table)
Pressure roller
Control panel
