Motor and Battery Installation
Required Parts
Airframe
Plywood motor mount
Motor w/hardware
Electronic speed control
Propeller
#2 x 8mm or #3 x 8mm wood screw (included with motor)
Hook and loop material
Required Tools and Adhesives
Foam-safe CA, Medium
Drill bit: 1/16" (1.5mm)
Cardstock
Felt-tip pen
Hobby Knife
Screwdriver, #0 Phillips
Optional
Variable pitch prop
Sub-micro servo (1)
 1. Locate the plywood motor mount and aluminum
X-mount for your particular motor. Center
the motor mount on the plywood and mark
the holes for the mounting screws using a
felt-tipped pen making sure the holes you mark
do not interfere with the carbon spars the mount
will glue into.
Hint:.If.the.hole.in.your.mount.matches.the.
diameter.of.the.hole.in.the.plywood.mount,.use.
a.rolled-up.piece.of.cardstock.placed.through.
the.two.holes.to.center.the.motor.mount.on.the.
plywood.mount.
