LTO

LTO

TM

20

Parameter & Functions Set-up Guide

Delay Unit

In

Out

Compressor/Limiter Threshold Unit

Temperature Unit

Units

Utility

Misc. Setup.

Output Meters

Temperature

LCD Contrast

: The options are uS (microseconds), ms (milliseconds), mm (millimetres) and m (metres). These

can be set separately for Input Delay and Output Delay, using the arrow keys to switch between

and

.

Use the rotary control to change the unit type.

: The options are dBu or V (Volts). Use the rotary control to change the

unit type.

: This relates to the temperature set as the ambient temperature when calculating delay

times. Use the rotary control to switch between Centigrade and Fahrenheit. Press ESC to quit the
submenu.

Select MODE

NEXT x2

Press ENTER.

Press NEXT to switch between the submenu options. Press ESC to quit this mode.

: No action - function not applicable to the RM2.

: A feature retained from the pro audio version of the device. It allows the current in-car

temperature to be keyed in using the rotary control. The system uses this value to compensate for the
variation in the speed of sound transmission when calculating time delay. This is far more applicable to
professional PA applications, where it allows the delays to be set during the sound-check and adjusted
automatically at the time of the concert if necessary.

One car application could be in autosound competition, if the temperature inside the vehicle changes
dramatically from when the system was set-up. In reality the distances involved between speaker drive units
in the car will almost certainly make temperature changes insignificant - but that doesn't stop you from
impressing the hell out of the guy next to you who doesn't have a UCS PRO installed!

: Adjust the contrast of the display using the rotary control - sometimes useful to compensate for

different viewing angles.

Miscellaneous Setup (Utility Menu):
