14
LED Indicators are located here
Press the MENU button and use the Up/Down Arrow buttons on the remote to access the different functions and acoustic settings of
the Sound Bar. Each function and setting will be displayed on the remote control’s LCD display. The LED Indicators will behave differently
with each function.
Function LED Behavior Description
Bluetooth Pairing
(When searching for device)
Flash from Left to Right
and back continuously.
Press the Play button on the remote. The Sound Bar will be discoverable for
15 minutes. You can now search for the Sound Bar (VIZIO S5430w) using your
Bluetooth Device. The sound bar will power down if no device is found.
Note: Set your Bluetooth device into pairing mode prior to the Sound Bar.
Bass Levels
Two center LEDs
indicate Bass level 0.
Press the Next/Previous button to increase/decrease the bass level. The
LED indicators will move to the right with increasing levels and to the left with
decreasing levels.
Treble Levels
Two center LEDs
indicate Treble level 0.
Press the Next/Previous button to increase/decrease the treble level. The
LED indicators will move to the right with increasing levels and to the left with
decreasing levels.
Dialog Levels
Two center LEDs
indicate dialog is
centered.
Press the Next/Previous button to increase/decrease the presence of dialog in
the virtual center channel. The LED indicators will move to the right when the dialog
presence is increased and to the left when the dialog presence is decreased.
Surround Levels
Two center LEDs
indicate surround is
centered.
Press the Next/Previous button to increase/decrease the virtual surround sound
level. The LED indicators will move to the right with increasing levels and to the left
with decreasing levels.
Note: DTS TruSurround must be On to adjust the surround level.
Subwoofer Levels
Two center LEDs
indicate Subwoofer
level 0.
Press the Next/Previous button to increase/decrease the level of the subwoofer.
The LED indicators will move to the right with increasing levels and to the left with
decreasing levels.
Note: Subwoofer not included.
BT Pair
Bass
Treble
Center
Surround
Subwoofer
SETTINGS AND LED BEHAVIOR
