First-time setup – Vizio M652i-B2 - Quickstart Guide User Manual
Page 10
Match colored connectors
to colored ports.
FIRST-TIME SETUP
Connect all of your devices first.
Choose ONE connection type for each device.
BACK OF TV
Red
White
Red
Blue
Green
Yellow
White
Red
1
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
