 Dolgin Engineering 1019 Massachusetts Ave. Lexington, MA 02420 • (781) 863-1813 • www.dolgin.net

1

Introduction

The Power Plate adapter is electrically compatible with all common 7.2V Li-Ion camera batteries. The
modular design allows for different battery models to be used when the appropriate adapter plate is fitted.
The Power Plate adapter is designed to power Panasonic Lumix GH2 cameras.

The PP adapter accepts Sony L/M (VX2xx or similar), Panasonic DVX100/HVX200/HPX170/HMC150,
and Canon BPxx (XL/GL) style batteries. The adapter must be configured with the appropriate plate to
match the battery style.

Operation

Mount a fully charged battery on the Power Plate adapter. The LED will illuminate. Connect the DC cable to
the

DMW-DCC8 DC Coupler

(not included).


Status LEDs
1. Green ON

Battery is fully charged

2. LED blinking 3 times

Battery is approximately at 3/4 charge level or less

3. LED blinking 2 times

Battery is approximately at 1/2 charge level or less

3. LED blinking 1 times

Battery is approximately at 1/4 charge level or less

4. LED strobs

Battery is discharged


* To extend batteries service life avoid running them down to below 1/4 level

Specification

Input Voltage

6.5V-8.4V

Output Current

up to 2A

Efficiency

~90%

Overload/short circuit protection set at 2.5A

Smart LED charge level indicator
