S.I.P. 300 8
TROUBLESHOOTING 5 TECHNICAL DATA 6
Power supply
• MAX 240V 50/60Hz
Input power
300VA
Lamp
• Halogen M38 300W
- Connection GY9.5
- Colour temperature 2,900 K
- Luminous flux (120V) 5,500 lm
- Luminous flux (230V) 5,000 lm
- Mean life 2,000 h
Optical unit
• Base in die-cast aluminium.
• Twin lens condenser.
• Spherical reflector with a high
luminous efficiency.
Lens units
• Standard: 1:2,4/100 mm (30,9°)
• Optional: 1:2,8/45 mm multi-lens (64,2°)
• Optional: 1:2,8/60 mm multi-lens (45,8°)
• Optional: 1:2,8/85 mm multi-lens (34,4°)
• Optional: 1:2,8/120 mm multi-lens (24,1°)
• Optional: 1:3,5/150 mm multi-lens (19,5°)
• Optional: 1:4/165 mm (17,2°)
• Optional: 1:4,4/200 mm (14,3°)
• Optional: 1:3,5/70÷120 mm zoom
(39,5°÷22,9°)
Body
• In die-cast and extruded aluminium.
• Epoxy powder painting.
Mounting
• Bracket in steel painted with epoxy
powders.
• Three installation positions with a step
of 25 mm (0.98”).
• Bracket adjustable on 120°.
Working position
Operation in any position.
Weights and dimensions
Weight: 2,3 kg (5 Ibs 1 ozs).
(14.13”)
359
(8.07”)
205
(8.86”) 225
(10.83”) 275
(5.12”)
130
(7.28”)
185 (6.69”)
170
POSSIBLE CAUSES CHECKS AND REMEDIES
CAUSE AND SOLUTION OF PROBLEMS
DEFECTIVE PROJECTION TROUBLE
REDUCED BRIGHTNESS
•
• •
•
• •
No mains supply. Check there is supply power.
Lamp exhausted or defective. Replace lamp (see instructions).
Lenses or reflector broken. Call an authorized technician.
Dust or grease deposited. Clean (see instructions).
