12
• PAN - channel 5
Operation with option 5 OFF
0
1
2
3
4
5
6
7
8
9
10
BIT %
255 100
0 0.0
OFF
ON
1 2 3 4 5 6 7 8 9 10 1112
Operation with option 5 ON
0
1
2
3
4
5
6
7
8
9
10
BIT %
255 100
0 0.0
OFF
ON
1 2 3 4 5 6 7 8 9 10 1112
• TILT - channel 6
Operation with option 6 OFF
0
1
2
3
4
5
6
7
8
9
10
BIT %
255 100
128 50.0
0 0.0
OFF
ON
1 2 3 4 5 6 7 8 9 10 1112
Operation with option 6 ON
0
1
2
3
4
5
6
7
8
9
10
BIT %
255 100
128 50.0
0 0.0
OFF
ON
1 2 3 4 5 6 7 8 9 10 1112
0
1
2
3
4
5
6
7
8
9
10
STOP
540 °
360 °
0 °
BIT % EFFECT
255 100 FAST ROTATION (120 rpm)
191 - 192 74.7 - 75.0 STOP
128 50.0 FAST ROTATION (120 rpm)
193 75.5 SLOW ROTATION (2 rph)
190 74.2 SLOW ROTATION (2 rph)
0 0.0
49.7 127 540 ° POSITION
41.7 105 450 ° POSITION
33.0 84 360 ° POSITION
24.7 63 270 ° POSITION
16.2 42 180 ° POSITION
8.2 21 90 ° POSITION
0 ° POSITION
• GOBO ROTATION - channel 8
0
1
2
3
4
5
6
7
8
9
10
BIT % EFFECT
204 - 255 80.0 - 100 GOBO 4
0 - 47 0.0 - 18.2 WHITE
152 - 203 59.5 - 79.5 GOBO 3
100 - 151 39.0 - 59.0 GOBO 2
48 - 99 18.7 - 38.7 GOBO 1
• FIXED GOBO SELECT - channel 9
0
1
2
3
4
5
6
7
8
9
10
BIT % EFFECT
208 - 255 81.7 - 100 GOBO 4
0 - 51 0.0 - 20.0 WHITE
156 - 207 61.2 - 81.2 GOBO 3
104 - 155 41.0 - 61.0 GOBO 2
52 - 103 20.5 - 40.5 GOBO 1
• ROTATING GOBO SELECT - channel 7
0
1
2
3
4
5
6
7
8
9
10
BIT % EFFECT
255 100 DISTANT
0 0.0 NEAR
• FOCUS - channel 10
Continua / Continue ➔
