ALPHA SPOT HPE 300 31
• LAMP CONTROL (only with option LDmx On) - channel 23
IMPORTANT: Alpha Spot HPE 300 is not provided with hot restrike igniter
LAMP ON
LAMP ON
BIT % EFFECT
255 100
180 70.5
0 0.0
101 39.5
ON
ON
OFF
100 39.0 LAMP OFF
179 70.0
26 10.0 LAMP OFF
25 9.7
OFF
UNUSED RANGE 1
UNUSED RANGE 2
The function is activated
staying 5 s in Lamp ON levels.
The function is activated
passing throug the unused
range 1 and staying 5s in
Lamp OFF levels.
• RESET - channel 22
BIT % EFFECT
255 100
128 50.0
127 49.7
77 30.0
76 29.7
26 10.0
25 9.7
0 0.0
Complete reset is activated passing
throug the unused range and staying
5 seconds in complete reset levels.
COMPLETE RESET
PAN / TILT RESET
PAN / TILT RESET
EFFECTS RESET
EFFECTS RESET
UNUSED RANGE
Pan / Tilt reset is activated passing
throug the unused range and staying
5 seconds in Pan / Tilt reset levels.
Effects reset is activated passing
throug the unused range and staying
5 seconds in Effects reset levels.
COMPLETE RESET
