Cineo Lighting Maverick - Manual (Page 11)

11
Specifications
Lamphead
Input voltage: 10.5-28 VDC
Power consumption: 75 watts / 120 watts / 135 watts (user configurable)
4-pin XLR power input
EtherCon DMX port
Completely silent, flicker-free operation
Fixture dimensions: 9.4” x 7.3” x 3” (240mm x 186mm x 78mm)
Weight: 2.2 kg (4.9 lbs)
Maximum output: 8,000 lumens
Beam Angle: >160º
Max. temperature rise: +45° C above ambient
Environmental temperature range: -20 - +50 C
35,000 hr. L70 rated
2-year parts and labor warranty
ETL and cETL pending, CE Compliant
Zero UV light emitted
Made in USA
Maverick Power Sources
120w AC Adapter
Part # 900.0095
Input Voltage: 100-240VAC
Output Voltage: 24VDC
Max. output current: 5A
Output connector: XLR4
Dimensions: 6.61” x 2.8” x 1.48” (168mm x 71mm x 37.2mm)
Weight: 1.5 lb. (680.3g)
2-year parts and labor warranty
UL, cULus and CE listed
